• Perfect for projects where your device occupies a port and your user still needs to plug in a mouse or keyboard.
• Wires to your project via standard 2 mm 7-pin connectors.
• Y-mouse^® PS/2 and Y-key key^® PS/2 versions are available from stock.
• Chips and specifications are also available.

Using the same proven hardware as the Y-mouse^® and Y-key key^® adapters, the Y-mouse^® header boards and chipsets reliably connect your project to the computer and an external keyboard or mouse.



Y-mouse^® and Y-key key^® PS/2 Header Board

Download a CAD file of the board here (Internet Explorer users please Right Click on the link and select the “Save Target As” option): HDBOARD1.DXF

Y-mouse^® and Y-key key^® PS⁄2 Pin Outs

Get AT Keyboard and PS/2 Keyboard and Mouse Pinouts here: pinouts.gif

Y-mouse^® PS/2 to USB Header Board

For a larger image of this board, please click here.

Ever wonder what's inside our famous Y-mouse microchip? Click here to see the incredible internal technology magnified 1,000,000 times: pichip.jpg
